Swiss Technology, 5/6 Axes, For Microminiature Workpiece

The BL-CSL075/076 series is an ultra-precision Swiss-type automatic lathe specifically engineered for microminiature workpieces ranging from 1-10mm. Utilizing advanced Swiss technology, this series is designed for industries where extreme precision is non-negotiable.

● Independent Dual-System Machining: The X1/Y1 and X2/Y2 axes can operate independently, enabling simultaneous rough and finish turning to maximize efficiency.

● Ultra-High Speed Capabilities: Standard main spindles feature 4 radial live tools, with an optional brushless high-speed electro-spindle capable of reaching 60000rpm .

● Rapid Setup Flexibility: Operators can switch between "fixed guide bushing" and "rotary guide bushing" modes in approximately 15 minutes to suit different part lengths.

● Precision and Stability: The series features a high-precision built-in electro-spindle with NSK super-high precision bearings, achieving a repeat positioning accuracy of 0.003mm.

Taiwan Technology, 6" Collet/Chuck, Gang Tool, Without Tailstock

Featuring a 45°mono-block slant bed structure, specifically designed for high-speed processing of small precision shaft components.

The unique gang-tool post eliminates tool-changing wait times, significantly shortening the production cycle for individual parts.

Combining Taiwanese technology with a high-speed spindle, it is the premier "speed champion" for high-output manufacturing of electronic connectors and communication components.

Taiwan Technology, 5"/6" Collet/Chuck, Gang Tool/8t Tool Turret, Without Tailstock

● Core Positioning: Engineered for high-efficiency and high-repeatability machining of small-scale parts.

● Key Parameters: 6-inch chuck, max speed up to 5000rpm, IT6 class precision turning.

● Technical Highlights: Adopts a compact Gang Tool structure to drastically reduce tool-changing time.

● Target Applications: High-volume production of small-diameter parts for electronics, medical, and pneumatic industries.

Japanese Technology, Single Spindle, 3 Axes

The BL-CSL123/203/263 series is a single-spindle, 3-axis Swiss-type lathe focused on high-speed, cost-effective production of slender parts that do not require back-end machining.

Streamlined 3-Axis Design: By focusing on a single-spindle total of 3 axes, this series offers a simple structure with exceptionally low distortion and high rigidity.

● Proven Precision: Even as a cost-effective solution, it maintains a spindle flop of  and uses NSK/NTN P4 class bearings.

● High-Speed Output: The main spindle can reach up to 10000rpm (CSL203/263), making it highly efficient for mass-produced standard components.

● Reliable Automation: When paired with an automatic bar feeder, this series becomes a tireless production line for precise, small-sized axles.

Taiwan Technology, 6"/8" Collet/Chuck, Gang Tool/12t Tool Turret, Without Tailstock

Based on a modular design concept, it can be flexibly configured with gang tools or a 12-station servo turret to meet various turning needs from simple to complex.

The rigid mono-block slant bed, paired with wide linear guideways, ensures exceptional rigidity and long-term precision stability during high-speed cutting.

With high cost-performance and adaptability, it is a versatile tool for hardware, plumbing parts, and automotive primary processing workshops.

Taiwan Technology, 6" Chuck, Gang Tool, Without Tailstock

● Core Positioning: Engineered for high-efficiency and high-repeatability machining of small-scale parts.

● Key Parameters: 6-inch chuck, max speed up to 5000rpm, IT6 class precision turning.

● Technical Highlights: Adopts a compact Gang Tool structure to drastically reduce tool-changing time.

● Target Applications: High-volume production of small-diameter parts for electronics, medical, and pneumatic industries.

Japanese Technology, Dual Spindle, 5 Axes

The BL-CSL125 is a dual-spindle, 5-axis Swiss-type lathe optimized for the high-efficiency production of small-diameter workpieces, particularly those between. It combines Japanese technology with a rigid structure for high-precision output.

● Integrated Multi-Tasking: This series achieves combined turning, milling, and drilling through side-mounted live tools and axes.

● High-Rigidity Construction: Built with Meehanite resin sand cast iron and subjected to aging treatment, the machine offers high heat stability and minimal distortion.

● Sophisticated Spindle Design: Features a built-in electro-spindle with NSK/NTN P4 class bearings, ensuring spindle flop remains.

● Compact Power: With a main spindle power of 1.5kw and a max speed of 10000rpm, it provides the ideal torque-to-speed ratio for small components.

6"/8" Collet Chuck, 8t Tool Turret & 4+4 Live Tool With Y Axes, Without Tailstock

The compact body features 4+4 independent live tools and a Box-way Y-axis, providing extremely stable radial and axial milling and drilling capabilities.

The 30°mono-block slant bed design ensures smooth chip removal and excellent vibration damping, ideal for precision composite machining of small parts made from high-hardness materials.

Designed to provide a one-stop integrated solution for parts requiring secondary side operations, such as home appliance motor shafts and sensor bases.

Japan Technology, 8" Chuck, 8t/12t Tool Turret, Hydraulic Tailstock

● Core Positioning: A versatile CNC lathe that perfectly balances speed and rigidity.

● Key Parameters: 8-inch chuck, max cutting diameter up to 380mm.

● Technical Highlights: Equipped with high-precision ROLLER linear guideways to ensure stability during high-speed movement.

● Target Applications: Medium and small-sized shaft parts in automotive and home appliance industries requiring high flexibility and surface finish.

Japanese Technology, Dual Spindle, 5 Axes

The BL-CSL205/265 series represents the standard for versatile, high-volume production of precise, slender axle workpieces. Adopting Japanese technology and structure, it utilizes high-tier components from Germany, Japan, and Taiwan.

● 5/6-Axis Dual Spindle Performance: The dual-spindle configuration allows for comprehensive machining of complex parts in a single setup.

● Precision Engineering: Equipped with high-precision built-in electro-spindles and THK/PMI linear guideways to maintain superior precision retention.

● Broad Capacity: Supports machineable bar diameters up to 20mm (CSL205) or 26mm (CSL265).

● Reliable Components: The series incorporates Schneider electrical parts and Airtac pneumatic components for industrial-grade reliability.

Taiwan Technology, 6"/8" Chuck, 12t Powered Tool Turret, Servo Programmable Tailstock

Inheriting the classic structure of Taiwan GOODWAY machines, it is equipped with a high-rigidity BMT55 powered turret for efficient axial and radial cutting.

Featuring a precision servo-programmable tailstock, it effectively supports and eliminates vibration for medium-to-long shafts, ensuring consistent accuracy across the full stroke.

Widely used in industrial fields such as precision drive shafts and hydraulic valve cores requiring high coaxiality and multi-process turn-mill integration.

Japan Technology, 6' Chuck, 12t Powered Tool Turret With Interpolation Ys Axes

● Core Positioning: Realizes "One-Clamp, Total-Completion" for complex and irregular parts.

● Key Parameters: Built-in electro-spindle design, C-axis indexing accuracy up to 0.001°.

● Technical Highlights: Equipped with a BMT power turret and Y-axis (Sub-spindle optional), providing robust turning, milling, drilling, and tapping capabilities.

● Target Applications: Complex parts with intricate processes in aerospace and medical device industries.
